A very simple, but useful PCB. A power supply for the Muffsy Relay Input Selector (or anything else that can be powered by 5V DC/1A):

I'd really like a stereo input selector with relays, but those things are hard to find! (Apart from some of dubious quality on the *Bay)

Better make my own then. This one's got a custom footprint for an ESP32 devkit module, but it can also be controlled with a rotary switch.

I've been getting my new hobby room ready, and I knew I needed some kind of stereo system in there. Preferably one that didn't annoy others in the house, so I ended up ordering PCBs from Nwavguy's gerber files. Yup, I'm gonna use headphones. :)

Here's the finished Inverse RIAA. I haven't done extensive testing yet, but it works as promised AND it measures exactly the same on both channels. I'm really happy with the result.

Get the gerbers for this project here: invRIAA.zip

This is my first venture into SMD components, so I'm going to have some fun with tools, solder paste, stencils and hot air. :)

Get the gerbers for this side project here: invRIAA.zip

Here's another project with freely available Eagle project files.

There was a strange little thing that appeared in Danish magazine Ny Elektronik (New Electronics) in 1989. A very simple preamplifier that used two L63 tubes in Class A with no feedback and it operated pretty much badly out of spec. (...

Here's a little side project, and it comes with Eagle Project files so you can order, etch and modify it anyway you like. All project files are available on this Hackaday.io project page: https://hackaday.io/project/18624-muffsy-constant-current-led-tester
